3586302100 CLIPPER DUO
Brush Deck Motor
*SEE SERIAL NUMBER PAGE.
**CALL MANUFACTURER FOR SERIAL NUMBER.
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86273750 6 SCR, 1/4-20 X 5/8 HHCS SS
2 86173340 6 WASHER, SPLIT LOCK, 1/4 SS
3 86010630 6 WASHER, 1/4 ID X 5/8 OD SS
4 86215880 2 BRKT, MOTOR MOUNT
5 86294490 1 BRUSH MOTOR ASM 115V INCLUDES #4, 16,17
6 86222290 3 NUT, 5/16-18 HEX NYLOCK SS
7 86346070 2 COUPLER, 2-JAW, 35MM *(2)
WAS 86217250
INCLUDES #9
8 86234600 1 COUPLER, SPIDER *(2) WAS 86217260
9 86172960 2 SCR, SET, M6X8, SH, ISO4029,SS
10 86225790 3 WASHER, 5/16 X .63 SS
11 86005640 3 NUT, 10-32 HEX NYLOCK
12 86002390 1 CLAMP, 1.75" WORM GEAR X .312
13 86198450 3 CLAMP, 5/16 NYLON
14 86276820 3 SCR, 10-32 X 1/2 PTHMS BLK NP
15 86216750 1 CLAMP, WORM GEAR 40-64MM
16 86332820 - RUN CAPACITOR 25 UF SERVICE
17 86332830 - START CAPACITOR 150 UF SERVICE
To Next Page
