3786302100 CLIPPER DUO
Brush Deck Mounting
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86302710 1 DEFLECTOR, SPRAY
2 86270830 11 NUT, 5/16-18 HEX NYLOCK SS
3 86010670 13 WASHER, 5/16 FLAT SS
4 86259410 4 WASHER, THRUST .51 ID X 1 OD X .063
5 86296450 1 BRKT, DECK ARM CROSSBAR
6 86228990 4 BEARING, FLNGD, .314 ID X .502 OD
7 86277130 8 SCR, 5/16-18 X 1.00 CARRIAGE SS
8 86295010 1 BRKT, DECK ARM RIGHT
9 86294940 1 BRKT, LEFT DECK HANGER
10 86294950 1 BRKT, RIGHT DECK HANGER
11 86270990 4 NUT, 10-32 HEX NYLOCK
12 86010650 4 WASHER, #10 X 9/16 OD
13 86071800 2 BRKT, BRUSH DECK PIVOT
14 86225790 1 WASHER, 5/16 X .63 SS C
15 86006580 2 SCR, 1/4-20 X 1/2 PPHMS SS DL
16 86301870 1 COVER, BRUSH DECK MOTOR
17 86008460 2 SPACER, .500OD X .391ID X .400
18 86296480 2 CUSHION, BRUSH DECK
19 86295020 1 BRKT, DECK ARM LEFT
20 86271840 1 NUT, 5/16-18 HEX NYLOCK THIN SS
21 86361560 1 GUARD, SPLASH
