Windsor 10080480 User Manual

4586302100 CLIPPER DUO
Handle
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86312730 3 SWITCH, HANDLE
2 86224500 4 SPACER, HANDLE EXTRUSION
3 86218660 1 HANDLE, GRIP
4 86223830 1 SCR, M8X40, SHCS, ISO 4762, SST
5 86173000 3 SCR, KA40X20, PT OVAL, WN1412, PL
6 86293400 4 SCR, M5X12 SHCS GR 10.9 PLT
7 86218960 1 HOOK, UPPER, CORD
8 86218950 2 HOOK, LOWER, CORD
9 86218640 1 HANDLE, EXTRUSION, LEFT
10 86218630 1 HANDLE, EXTRUSION, RIGHT
11 86216500 2 CABLE - ACTUATION, HANDLE
