4786302100 CLIPPER DUO
Handle Bracket
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86276800 5 SCR, 10-32 X 3/8 HHMS SS
2 86279170 6 WASHER, #10 X 1.0 FLAT
3 86296830 2 BRKT, HANDLE PIVOT
4 86296860 2 PLATE, HANDLE PIVOT LATCH
5 86296880 1 LEVER, HANDLE RELEASE LEFT
6 86296890 1 LEVER, HANDLE RELEASE RIGHT
7 86296920 1 BRKT, HANDLE TANK MOUNT
8 86296970 1 MECHANISM MOUNT, LEFT
9 86296980 1 MECHANISM MOUNT, RIGHT
10 86302860 2 SPRING, EXT .25D X 1.13L X .031W
11 86298840 1 SCR, 10.32 X 1.0 HHMS PLT
12 86233170 1 CLAMP, 3/8 NYLON UL/CSA
13 86005640 1 NUT, 10-32 HEX NYLOCK
14 86274400 4 SCR, 1/4-20 X 5/8 BHCS
15 86298830 2 NUT, 10-32 LOCK DT 1/8 THK PLT
16 86312160 1 KIT HANDLE PIVOT LEFT
INCLUDES
#3,4,5,8 AND 10
17 86324360 1 KIT HANDLE PIVOT RIGHT
INCLUDES
#3,4,6,9 AND 10
To Next Page
