5586302100 CLIPPER DUO
Solution
*SEE SERIAL NUMBER PAGE.
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86308240 1 GASKET, SOLUTION ASSY
2 86197420 1 ELBOW, 3/8 NPT STREET
3 86218360 2 GROMMET, 3/4 ID X 7/8 GROOVE
4 86200280 1 HOSEBARB, 3/8 MPT X 1/4 90D
5 86005640 4 NUT, 10-32 HEX NYLOCK
6 86273930 2 SCR, 8-32 X 1/2 PPHMS
7 86006790 2 SCREW 10-32 X 3/8 HHTR W/STAR
8 86274290 2 SCR, 10-32 X 3/8 PPHMS SS
9 86298840 4 SCR, 10-32 X 1 HHMS PLTD
10 86010650 4 WASHER, #10 X 9/16 OD
11 86197940 1 HOSEBARB, 3/8MPTX1/2 90D DL
12 86294700 1 BRKT, SOLUTION ASSY
13 86294720 1 ASSY, FRAME, SOLUTION
14 86297930 4 GROMMET, .50ID X .06
15 86298120 1 NUT, SPEED, #8-32
16 86299120 1 TERMINAL STRIP, 4-POS, .25
17 86358710 1 HOSE ASSEMBLY
18 86281980 1 HOSE, 1/2D WIRE BOUND X 5"
19 86298070 1 ASSY, PUMP, 110V
20 86233150 3 CLAMP, 3/8 HOSE (D-SLOT)
21 86240530 1 HOSEBARB, 1/2 X 1/4 X 1/2, TEE
To Next Page
