5786302100 CLIPPER DUO
Solution
*SEE SERIAL NUMBER PAGE.
**CALL MANUFACTURER FOR SERIAL NUMBER.
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86233090 9 CLAMP, 1/4 ID HOSE
2 86233150 2 CLAMP, 3/8 HOSE (D-SLOT)
3 86281060 4 HOSE, 1/4 ID NYLOBRD X 8"
4 86197640 2 HOSEBARB, 1/8" FPT X 1/4"
5 86270780 1 NUT, 8-32 HEX
6 86273930 2 SCR, 8-32 X 1/2 PPHMS
7 86006520 6 SCR, 8-32 X 3/8 PPHMS SS
8 86295050 1 PLATE, BOTTOM
9 86295060 1 COVER, SIDE
10 86297210 1 COVER, NOZZLE MOUNT
11 86297850 1 CLAMP, SOLENOID PUMP
12 86297890 1 TERMINAL STRIP, 3-POS, .25
13 86299330 1 HARNESS, HANDLE CONNECTOR
14 86281980 1 HOSE, 1/2ID WIRE BOUND X 5"
15 86300310 1 BUSHING, STRAIN RELIEF
16 86301050 1 HOSE, 1/4 ID NYLOBRD X 27"
17 86310710 1 SCR, 8-32 X 1/2" PFHMS PLT
18 86256090 1 STRAINER, 1/2 NPT 80 MESH
19 86298090 1 ASSY, NOZZLE MOUNT
20 86001530 2 HOSEBARB, 1/2MPT X 1/2 HOSE 90
21 86297230 1 BAFFLE, ACOUSTIC
22 86297440 1 JET, PROMAX, 11008
23 86012550 1 JET, PROMAX, 11001
24 86004570 2 JET BODY, MINI PROMAX BODY
25 86010820 2 WASHER, 7/16 X 3/4 X .19 RUBBER
26 86197400 3 ELBOW, 1/8NPT STREET
27 86240610 4 HOSEBARB, 1/8 MPT X 1/4H 90D
28 86197750 1 TEE, 1/8 NPT STREET RUN
29 86297290 1 VALVE, SOLENOID, 120VAC, 1/8 NPT
30 86197520 1 HOSEBARB, 1/8MPT X 1/4 DL
31 86353090 2 SCR, 8-32 X 5/16 PPHMS SS
32 86201110 1 PUMP, 110/120 60 HZ FLOJET
33 86302620 1 FOAM, 1 X 1 X 18
34 86302640 1 FOAM, SOLN ASM LID
35 86010640 3 WASHER, #10 LOCK EXT STAR SS
36 86245040 1 LABEL, GROUND SYMBOL
37 86010650 1 WASHER #10 X 9/16 OD
38 86006800 1 SCR, 10-32 X 1/2 PHTR PLT
39 86310230 1 COVER, SOLN ASM, LOWER, TRIM
40 86006790 7 SCREW 10-32 X 3/8 HHTR W/STAR *(3)
