6386302100 CLIPPER DUO
Vacuum Shoe Mounting
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86003010 1 CUFF. HOSE 1.5" BLK A 2161
2 86004290 1 HOSE, 1.5 BLK VAC X 45"
3 86002390 1 CLAMP, 1.75" WORM GEAR X .312
4 86297470 1 ASM, TRAVEL LIMITER
5 86276490 2 SCR, 5/16-18 X 5/8 HHCS SS
6 86010670 2 WASHER, 5/16 FLAT SS
7 86295030 2 SPRING, EXT .562D X 6.0L X .072W
8 86278280 2 SHOULDER BOLT
9 86296510 1 BRKT ASM, VAC SHOE MOUNT
10 86005810 2 NUT, 1/4-20 HEX NYLOCK SS
11 86259420 2 WASHER, THRUST .51 ID X 1 ODBRO
12 86272750 1 RING, 5/8 EXTERNAL SNAP
13 86010730 1 WASHER, 5/8
14 86298080 2 SCR, 5/16-18 X 3/4 FHSC SS
15 86259410 2 WASHER, THRUST .51 ID X 1 OD X .063
16 86010630 2 WASHER, 1/4 ID X 5/8 OD SS
17 86273750 2 SCR, 1/4-20 X 5/8 HHCS SS
18 86293160 2 VAC SHOE ASM 18"
19 86300340 1 BLOCK, DECK LINKAGE
20 86014990 1 SCR, M5X20, SHCS, ISO4762, SS
To Next Page
