Windsor 10080480 User Manual

6986302100 CLIPPER DUO
Wiring Diagram
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86296060 1 HARNESS, HANDLE
2 86297750 1 CORD ASM, 14/3 X 22 PGTL
3 86298180 1 WIRE, 540MM BLU/18 76046XSTRIP
4 86296010 2 WIRE, 240MM ORG/18 76031X76046
5 86296020 1 WIRE, 150MM RED/18 76031X76046
6 86295980 1 WIRE, 605MM BRN/18 76046X76047L
7 86268210 1 WIRE, 15" GRN/18 76008 X 76008
8 86295990 2 WIRE, 80MM BLU/18 76031X76046
9 86296000 2 WIRE, 150MM WHT/18 76046X6046
10 86299330 1 HARNESS, HANDLE CONNECTOR
11 86299370 1 WIRE, 10"WHT/14 76029 X 76029
12 86299340 1 HARNESS, BRUSH DECK
13 86299360 1 WIRE, 10" RED/14 76029 X 76029
14 86294220 1 BRUSH DECK WIRING HARNESS
15 86312170 1 HANDLE HARNESS CONNECTOR
