Windsor Chariot 3 iScrub 26 CSC26 - Squeegee Disk

24
Operations
Squeegee Disk
1. Squeegee Handle
The squeegee handle holds the squeegee in place.
2. Squeegee Hose and Tube
The squeegee hose and tube carry the recovered solution to the recovery tank.
3. Squeegee Wheels
The squeegee wheels support the squeegee at the correct height and angle to automatically obtain optimum
suction. The squeegee requires no adjustment.
1
2
3
86395370 Operator Manual - Chariot 3 iScrub 26
