Windsor Chariot 3 User Manual

10386367610 Chariot CS26
Squeegee - Disk
* SEE SERIAL NUMBERS PAGE
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86367800 1 SCR, 1/4-20 X 3.00 CARRIAGE SS
2 86364090 4 SCR, 5/16-18 X 2.50 CARRIAGE, SS
3 86364080 2 SCR, 1/4-20 X 2.00 CARRIAGE, SS
4 86363100 1 SPRING, 2.5" X .66 OD COMP
5 86363070 1 PLATE, SLIDE, SQUEEGEE BASE
6 86006200 2 PIN, CLEVIS, 5/16 X 1.5 STL ZNPLT
7 86362420 1 ROD, 1/4" OD 9.13 LG, SS
8 86362400 1 HANDLE, 1/4-20 X 1" LG STUD
9 86362390 1 CASTER, SWIVEL, 2" WHEEL
10 86360310 1 NUT, 1/4-20 FLG SS NYL
11 86359830 2 SCR, 1/4-20 X 1.75 CARRIAGE SS
12 86359630 1 PLATE, BASE, SQUEEGEE
13 86359620 1 PLATE, SQUEEGEE, BOTTOM HDLR
14 86359610 1 PLATE, SQUEEGEE, BOTTOM
15 86359600 1 PLATE, SQUEEGEE, TOP
16 86359590 2 WHEEL,2.0ODX.31IDX.875 GRY
17 86359580 1 BLADE, SQUEEGEE, FRONT
- 86391560 1 BLADE, SQG, FRONT, 36 X URE OPTIONAL PART
18 86359570 1 BLADE, SQUEEGEE, REAR
- 86391570 1 BLADE, SQG, REAR, 40 X URE OPTIONAL PART
19 86358610 1 SQUEEGEE FRAME, RH
20 86358600 1 SQUEEGEE FRAME, LH
21 86358590 1 TUBE, PASS THROUGH, SQUEEGEE
22 86292500 4 WASHER, .324ID X .567OD X .057, SS
23 86278910 6 WASHER, 3/8 X 7/8 FLAT SS (1)*
24 86276710 2 SCR, 5/16-18 X 2.0 CARRIAGE
25 86271870 4 NUT, 1/4-20 HEX NYLOCK THIN SS
26 86271840 2 NUT, 5/16-18 HEX NYLOCK THN SS
27 86271240 2 NUT, CAP, PUSH, .25"
28 86270930 1 NUT, 1/4-20 HEX JAM SS
29 86270830 4 NUT, 5/16-18 HEX NYLOCK SS
30 86219690 4 KNOB, 1.5 OD X 5/16-18
31 86011020 2 WHEEL, 3" DIA. CUSHION RUBBER
32 86226370 1 BUSH, BRZ FLG .25 X .38 X .38 (1)*
33 86008660 2 COTTER, 5/16 RING
34 86005650 2 NUT, 5/16-18 HEX
35 86005630 1 NUT, 3/8-16 HEX NYLOCK THIN S
36 86001350 2 BUSHING, SPANNER .435 X 1.10
37 86372200 - SQUEEGEE ASM, CS26 COMPLETE
