Windsor Chariot 3 User Manual

25
Operations
Squeegee - Cylindrical
1. Squeegee Knobs
The squeegee knobs hold the squeegee in place.
2. Squeegee Hose and Tube
The squeegee hose and tube carry the recovered solution to the recovery tank.
3. Squeegee Wheels
The squeegee wheels support the squeegee. The height can be adjusted by turning the knobs.
1
2
3
86367610 Chariot CS26
