Windsor Chariot 3 User Manual

10586367610 Chariot CS26
Squeegee - Cylindrical
REF PART NO.
PRV
NO.
QT
Y
DESCRIPTION
SERIAL NO.
FROM
NOTES
1 28852940 - 1
END PIECE LEFT / RIGHT SPARE PARTS
SET
2A 62732070 - 1
RUBBER LIP SET OIL RESISTANT BR-
BD530,55
2B 62732900 - 1 RUBBER LIP SET STANDARD
2C 62732290 - 1
RUBBER LIP SET ANTI STRIPE OIL
RESISTANT
3 73061420 - 2
CYLINDER HEAD SCREW M 8X25-A4-70
ISO 47
4 73120170 - 2 WASHER 8-A2 ISO 7089
5 51005590 - 1 SUCTION BAR SUPPORT PLATE
6 50336010 - 1 SUCTION NIPPLE
7 47774110 - 1 SUCTION BAR CURVED 850MM Complete
8 63212390 - 2 STAR GRIP VA Ø50X43
9 50942310 - 2 SLEEVE SUCTION BAR IN VA
10 55153460 - 2 DEFLECTOR ROLL SUCTION BAR D120
11 53052960 - 2 WING SCREW M8X40 VA
12 51128100 - 2 SLEEVE VA
13 50072170 - 1 PLATE
14 73114310 - 2 HEXAGON NUT M 5-1.4305 ISO 10511
15 63212400 - 2 STAR GRIP WITH INSCRIPTION VA Ø50x43
16 40353390 - 2 ROLLER SUCTION BAR
17 51005600 - 2 ADDITIONAL WEIGHT SUCTION BAR 300 G
18 73061850 - 2 SCREW M5x 35-A2-70 (IN6RD)
19 73433030 - 2 LOCKING RING 8-A2 DIN 6799
20 64354010 - 2 WHEEL D54
21 53325040 - 2 PRESSURE SPRING
22 53040980 - 2 BOLT
23 51283390 - 1 ADDITIONAL WEIGHT SUCTION BAR

Windsor Chariot 3 Specifications

General

Brand	Windsor
Model	Chariot 3
Category	Scrubber
Language	English
