10786367610 Chariot CS26
Squeegee Lift
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86364040 1 BUSH, PLN,.251 X .313 X .75L
2 86364030 1 SCR, 1/4-20 X 2-1/4, GR-8, ZN
3 86364020 1 SCR, 1/2 X 1-1/4 SSHLD, SS
4 86362820 1 BUSH, PLN,.510 X .750 X .375L
5 86362310 3 WASHER, .51 X .89 X .06, UHMW
6 86362300 1 BUSH, PLN, .25I X .375 X .50L
7 86362290 1 BUSH, FL, .313 X .438 X .375L
8 86362270 2 SPACER,.196X.375X.438L NYL
9 86362260 1 BUSH, PL, .250 X .500 X .625L
10 86362250 1 PLATE, PULLEY, LIFT, UPPER
11 86362240 1 ASM, ARM, LIFT
12 86362230 1 PLATE, ACTUATOR MOUNT
13 86362220 1 BRKT, ACTUATOR, MOUNT
14 86362210 1 U-BRACKET, PULLEY
15A 86354470 1 CABLE, .09 X 26.63, 0707, SS DISK
15B 86370440 1 CABLE, .09 X 30.00, 0707, SS CYLINDRICAL
16 86320880 1 ACTUATOR, 36VDC, 3.0" STK, 8.74 LNG
17 86317330 2 PULLEY, 2 IN.
18 86273810 1 SCR, 1/4-20 X 1.00 HHCS SS
19 86273750 6 SCR, 1/4-20 X 5/8 HHCS SS
20 86272620 1 PIN, CLEVIS 1/4 X 1.13 PLTD
21 86272470 2 PIN, CLEVIS 3/16 X .75 PLTD
22 86272330 1 PIN, CLEVIS 1/4 X 2.44 PLTD
23 86271870 2 NUT, 1/4-20 HEX NYLOCK THIN SS
24 86270870 2 NUT, 1/4-28 HEX SS
25 86264920 1 CABLE TIE, 7" UL/CSA
26 86010630 9 WASHER, 1/4 X 5/8 FLAT SS
27 86008650 4 COTTER, 1/4 RING
28 86006560 1 SCR, 5/16-18 X 1.00 HHCS SS
29 86005630 1 NUT, 3/8-16 HEX NYLOCK THIN SS
To Next Page
