11386367610 Chariot CS26
Steering
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86361370 1 ASM, TENSIONER PLATE
2 86361210 1 SCR, 3/8-16 X 0.625 SHCS
3 86358400 1 SHAFT, LOWER STEERING 21
4 86358390 1 SHAFT, UPPER STEERING 9.0
5 86358380 1 CHAIN , 12.7MM PITCH, 118 ROLLER
6 86333950 1 BEARING, .75ID X 1.0OD X .63
7 86330720 1 CHAIN TENSIONER
8 86278940 2 WASHER, 1/4 X 1-1/4 FLAT
9 86277410 2 SCR, 5/16-18 X .625 CARR SS
10 86274330 1 SCR, M6 X 20 HHMS PLTD
11 86272900 1 RING, 3/4 KLIP
12 86271840 3 NUT, 5/16-18 HEX NYLOCK THN SS
13 86271610 1 NUT, 5/8-18 HEX NYLOCK THIN
14 86271840 2 NUT, 5/16-18 HEX NYLOCK THIN SS
15 86228790 1 BEARING, FLG,.88 OD X .75 ID X .75
16 86228670 1 BEARING-BALL FLANGED SEALED ONE
17 86224810 1 SPROCKET, DRIVE WHEEL STEERING
18 86224800 1 SPROCKET, STEERING SHAFT
19 86224270 1 SLEEVE, CHAIN TENSIONER
20 86219650 1 KEY, 5MM SQ X 39MM L
21 86219600 1 JOINT, UNIVERSAL FEMALE
22 86135970 1 KEY, 3/16 SQ X 11/16 LG CRS
23 86010780 1 WASHER, 1/4 SPLIT
24 86010670 5 WASHER, 5/16 X 3/4 SS
25 86008610 2 FLANGE, BEARING PRESSED STEEL
26 86005630 1 NUT, 3/8-16 HEX NYLOCK THIN SS
27 86001030 1 BEARING, BALL 3/4 BORE SPHERED
28 66403520 1 COVER, STEERING WINDSOR
29 64357990 1 WHEEL, STEERING AKW
30 86279130 2 WASHER 5/16 SPLIT LOCK PLTD
31 86361110 1 BRKT, STEERING
32 86278080 4 SCREW, 5/16-18 X 1.75 SCHSET CP SS
33 86270830 4 NUT, 5/16-18 HEX NYLOCK SS
34 86367250 1 WASHER, .344ID X 1.13OD X .09T SS
