Windsor Chariot 3 User Manual

11786367610 Chariot CS26
Vacuum
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86360990 1 HOSE, 1.5 BLK VAC X 40”
2 86360320 2
SCR, SET 1/4-20X3 HEX SKT CUP PT
SS
3 86360310 3 NUT, 1/4-20 FLG SS NYL
4 86360270 1 GASKET, .188 X .31 X 22.8
5 86359040 1 VAC HOUSING, UPPER
6 86359030 1 VAC HOUSING, LOWER
7 86358110 1 VAC MOTOR, 36VDC 2ST PD
8 86327500 3 MOUNT, VIBRATION
- 86326980 1 BRUSH SET 24/36V VAC WINDSOR
9 86317630 4 SCR, #8 X 3/4" PPHSMS TYPE AB
10 86312920 1 GASKET, VAC MOTOR
11 86280990 1 HOSE, VAC EXHAUST X 24”
12 86276350 1 SCR, 1/4-20 X 2.50 CARRIAGE
13 86270770 1 NUT, 1/4-20 HEX
14 86002390 2 CLAMP, 1.75 WORM GEAR X .312
15 86002380 1 CLAMP, 2.25 WORM GEAR
