12186367610 Chariot CS26
Wiring-Components
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86361230 2 CLAMP, PAN 3/4"
2 86361220 4 CLAMP, PAN 1-1/4"
3 86326270 1 CLAMP, 1.5 DIA
4 86264940 1 CABLE TIE 11.38" UL/CSA
5 86239720 1 HORN, 108DB MINATURE W/RING
6 86238500 1 GROMMET,1.703IDX2.5.ODX.125GRV
7 86238430 2 GROMMET 1.00 ID 3/16 GRIP
8 86006980 2 SCREW, 10-32 X .5 HHCS SS
9 86198460 1 CLAMP, 5/8 NYLON UL/CSA
To Next Page
