Windsor Chariot 3 User Manual

14186367610 Chariot CS26
Chemical Metering Solution System - Cylindrical
REF PART NO. QTY DESCRIPTION
SERIAL
NO.
FROM
NOTES
1 64290380 1 FLOWMETRE
2 86364390 1 PUMP, CHEMICAL DOSING
- 40354760 1 HOSE KIT REPLACEMENT
3 86363990 1 BRKT, CHEMICAL PUMP
4 86363980 1 HOSE, 5/8ID X .12W CLR X 25"
5 86363950 1 HOSE, 1/2ID WIREBOUND X 6.25”
6 86363940 1 PAD, CHEMICAL PUMP
7 86371740 1 HOSE, 3/16ID X 5/16OD X 24, CLR
8 86401590 1 HOSE, 3/16ID X 5/16OD X 47, CLR
9 86363880 1 CAP, 70MM DISPENSING, FLTR, BLK
10 86362850 1 O-RING, .86 ID X .14 W, BUNA-N
11 86362840 1 FTG, 1/2 MPT X 1/2 CONDUIT, NYL
12 86361690 1 VALVE, 36V SOL, 1/2 BARB, MC
13 86006520 2 SCR, 8-32 X 3/8 PPHMS SS
14 86361230 1 CLAMP, PAN 3/4”
15 86359010 1 CHEMICAL BOTTLE
16 86271850 1 NUT, 1/2 NPT PLASTIC
17 86264930 1 CABLE TIE, 3.5" UL/CSA
18 86233150 6 CLAMP, 3/8 WORM GEAR
19 86197940 1 HOSEBARB, 3/8 MPT X 1/2 HOSE 90
20 86006580 1 SCR, 1/4-20 X 1/2 PPHMS SS DL
21 86370840 1 HOSE, 1/2ID WIREBOUND X 9.25"
22 86302770 1 HOSE, 1/2ID WIREBOUND X 14”
23 54433750 1 HOSE STEM
24 63621700 1 O-RING SEAL 11,3 X 2,4-NBR 70
25 86402240 1 GASKET, 2.66OD X .06 THICK
26 86402340 2 CLAMP, HOSE, .38 BAND
- 86369920 - CAP, STORAGE, 70 MM
- 86370450 - KIT, CHEMICAL BOTTLE 3-PACK
