Windsor Chariot 3 User Manual

14786367610 Chariot CS26
Battery Exchange - 1
* SEE SERIAL NUMBER PAGE
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86359450 1 BRACKET, SPRING COVER, CART
2 86359400 1 BRKT, TRAY CATCH
3 86359390 1 BRACKET, BACK, CART
4 86359380 1 ASM, FRAME, BATTERY CART
5 86358190 2 GLIDE, BATTERY TRAY
6 86277470 2 SCR, 5/16-18 X 1.5 CARRIAGE SS
7 86276790 4 SCR, 5/16-18 X 1.75 HHCS SS
8 86276710 1 SCR, 5/16-18 X 2.0 CARRIAGE
9 86276690 4 SCR, 5/16-18 X 1.75 CARR SS
10 86276070 17 SCR, 5/16-18 X 3/4 CARRIAGE SS
11 86270830 32 NUT, 5/16-18 HEX NYLOCK SS
12 86259420 2 WASHER, THRUST.51 ID X 1 ODBRO
13 86254890 1 SPRING, EXT, .50D X 4.0L
14 86232590 2 CASTER, PT20
15 86231090 1 BUMPER, RUBBER 5/16" ID X 1.50
16 86228840 1 BEARING, FLANGED .313IDX.502OD
17 86199430 2 CASTER, SWIVEL 4” 250# CPCTY
18 86078890 4 PLATE, CASTER SPACER
19 86076600 2 HANDLE, BATTERY CART
20 86011020 2 WHEEL, 3" DIA. CUSHION RUBBER
21 86010670 6 WASHER, 5/16 X 3/4 SS
22 86007020 1 SCR, 5/16-18 X 1.25 HHCS SS
23 86400810 6 SCREW, 1/4-20 X .75 PHFLHMS SS (4)*
24 86004070 2 GRIP, POLISHER HANDLE
25 86001350 2 BUSHING, SPANNER .435 X 1.10
26 86244280 1 LABEL, BATTERY CART OPERATION
