Windsor Chariot 3 - Page 149

14986367610 Chariot CS26
Battery Exchange - 2
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86359440 1 BRACKET, PEDAL, CART
2 86359430 2 PLATE, LATCH LINK, CART
3 86359420 2 PLATE, PEDAL LINK, CART
4 86359410 2 PLATE, LATCH, CART
5 86277470 4 SCR, 5/16-18 X 1.5 CARRIAGE SS
6 86276070 2 SCR, 5/16-18 X 3/4 CARRIAGE SS
7 86270830 10 NUT, 5/16-18 HEX NYLOCK SS
8 86259420 6 WASHER, THRUST.51 ID X 1 ODBRO
9 86259410 4 WASHER, THRUST .51 ID X1ODX.063
10 86259400 4 WASHER, THRUST .51 ID X 1 ODBRO
11 86254280 4 SPACER,1.00 OD X .32 ID X .375
12 86231150 2 BEARING FLANGED .314IDX.502OD
13 86228840 6 BEARING, FLANGED .313IDX.502OD
14 86226830 2 SPRING, EXT. 1.00 OD X 4.O L
15 86010670 8 WASHER, 5/16 X 3/4 SS
16 86007020 2 SCR, 5/16-18 X 1.25 HHCS SS
17 86006560 2 SCR, 5/16-18 X 1.00 HHCS SS
