15186367610 Chariot CS26
Battery Exchange - 3
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86360040 1 BATTERY STOP, LEFT
2 86360050 1 BATTERY STOP, RIGHT
3 86319670 2 SLEEVE, BEARING
4 86363760 2 PLATE, SHIM .030" THIC
5 86010670 2 WASHER 5/16 FLAT SS
6 86007020 2 SCREW, 5/16-18 X 1.25 HHCS SS NP
7 86279190 2 WASHER, 10 FLT TYPEB FLT ZNPLT
8 86360090 2 STANDOFF, RND, 3/8 OD, 10-32 X3/8
9 86298200 2 STANDOFF, .43 OD, 1/4-20 X.75 L
10 86360060 1 BRKT, SPING MOUNT, LT
11 86360070 1 BRKT, SPRING MOUNT, RT
12 86254890 2 SPRING EXT, .50 D X 4.0 L
13 86010670 2 WASHER 5/16 FLAT SS
14 86270830 2 NUT, 5/16-18 HEX NYLOCK S
15 86273780 2 SCREW, 1/4-20 X .75 HHCS SS NP
To Next Page
