7186367610 Chariot CS26
Drive Mounting
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86366140 4 M10 X 25MM, FLANGE HH BOLT, GR 10.9
2 86366130 4 3/8-16 X 1, FLANGE HH BOLT, GR 8
3 86364130 1 ASM, SHAFT DRIVE MOTOR
4 86361070 1 BRKT, WIRING, DRIVE UNIT
5 86218360 1 GROMMET, 3/4 ID X 7/8 GROOVE
6 86357870 1 ASM, BEARING BLOCK, FRT DRIVE COMPLETE
7 86357120 1 HUB, DRIVE WHEEL MOTOR, 36V COMPLETE
8 86270990 1 NUT, 10-32 HEX NYLOCK SS
9 86264940 3 CABLE TIE, 11.38" UL/CSA
10 86357130 1 BRAKE
11 64358540 1 WHEEL DRIVE WHEEL MOTOR
12 86223980 2 BEARING, SEALED BALL, 25MM X 52MM
- 66132310 - CARBON BRUSH SET
To Next Page
