7386367610 Chariot CS26
Frame
* SEE SERIAL NUMBER PAGE
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86360820 1 ASSY, MAIN SUPPORT, CS26
2 86360710 1 ASM, WHEEL GUARD
3 86358190 2 GLIDE, BATTERY TRAY
4 86357950 2 PAD, TIP
5 86277410 6 SCR, 5/16-18 X 5/8 CARRIAGE SS
6 86276890 6 SCREW 5/16-18X3/4 PTHMS SS
7 86276490 2 SCREW 5/16-18 X 5/8 HHCS SS
8 86010670 2 WASHER 5/16 FLAT SS
9 86400810 6 SCREW, 1/4-20 X .75 PHFLHMS SS (4)*
10 86368240 6 NUT,5/16-18, FLGNYLOCK,SS
11 86361210 2 SCR, 3/8-16 X 0.625 SHCS
12 86005770 2 NUT 3/8-16 HEX NYLOCK
13 86006640 2 SCREW 5/16-18 X 1/2 SHCS NP
14 86270830 2 NUT 5/16-18 HEX NYLOCK SS
15 86368730 1 FOAM, ADH BACKED 1-SIDE, 6X1.5 X1.5
To Next Page
