7786367610 Chariot CS26
Platform Footbox & Rear Wheels
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86361130 2 PLATE, PLATFORM SUPPORT
2 86271840 4 NUT 5/16-18 HEX NYLOCK THIN SS
3 86361140 4 SPACER, 1.50 X .625OD X .065" WALL
4 86358000 1 FOOTBOX, OPERATOR PLATFORM
5 86361120 1 COLLAR, SHFT 1"ID X 1-5/8"OD X 5/8"
6 86357990 1 AXLE, REAR
7 86232130 2 CAP 2.75 ID X 1.0 L BLK VINYL
8 86335520 2 WHEEL, 10 X 2.5, PLSTC HUB, W/BEARINGS
9 86326490 4 SCR, 5/16+18 X 3.0 CARRIAGE, SS
10 86361150 2 PLATE, TANK SUPPORT
11 86224320 4 SPACER, .63 OD X .385ID X .64L
12 86008710 2 RING 3/4" EXT SNAP H-D
To Next Page
