8386367610 Chariot CS26
Scrub Deck - Cylindrical
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 50448660 2 RETAINER PLATE TRANSMISSION
2 73060310 10 SCREW M 6X16-A2-70 DIN 7984
3 73120260 10 WASHER 6-A2 ISO 7090
4 73130030 10 SPRING WASHER B 6FST-A3E DIN 127
5 50448580 2 HOLDER-UP
6 50560100 2 ROCKER BR-VS
7 51005530 2 DRIVESHAFT BR 65/90
8 73180020 2 PARALLEL KEY 5X5X16-C45R DIN 6885-1
9 73430150 2 LOCKING RING 15X1-FST-RF DIN 471
10 51163400 2 BOLT HOLDER-UP
11 73056370 2 COUNTERSUNK SCREW M8X16-A2-70 ISO 10642
12 51163540 2 BRUSH TRANSMISSION BR
13 56254830 2 BELT PULLEY 57MM
14 63431490 2 QUICK-FASTENER
15 63484420 2 RIBBED V-BELT
16 63631580 2 JOINT RING NILOSRING
17 50332060 4 LOCKING PART
18 74011150 4 BALL BEARING 6002-2RS-WAELZLAGST DIN 62
19 73432310 2 LOCKING RING 32X1,2-ST-PH DIN 472
20 73030470 5 SCREW M6X16-ST-R3R (IN6RD)
21 50333940 2 LOCKING PART
22 50332410 1 COVERING CAP LEFT
23 73030370 28 SCREW M5X10-ST-P2R (IN6RD)
24 50332420 1 COVERING CAP RIGHT
25 50334030 1 COVER PLATE
26 55150960 2 ROLLER
27 53830970 1 DECAL
28 50615800 1 BRUSH HOUSING BR 65
29 50707530 1 TANK REFUSE 65
30 51902610 1 STRIP WATER DISTRIBUTOR
31 46239200 2 MOTOR COMPLETE 24V/600W
32 66102160 1 CARBON BRUSHES
33 66130250 2 BLOWER WHEEL
34 53948230 2 SPLASH GUARD
35 50448670 2 RETAINER STRIP SPLASH GUARD
36 50094010 1 BRACKET RIGHT SCRAPER LIP
37 50094020 1 BRACKET LEFT SCRAPER LIP
38 51163390 2 THREADED BOLT
39 50332400 2 HAND WHEEL
40 63304070 2 SPRING CLIP
41 63908920 1 SPIRAL HOSE
42 66463290 2 RED PLUG
43 66463300 2 BLUE PLUG
44 73031070 3 SCREW 5X16-10.9-P2R (K-IN6RD)
45 66469790 4 SWITCH CONTACT
46 63884820 1 HOSE COUPLING
47 63211960 1 STAR GRIP M5X10
48 86370230 1 BRKT, DECK MOUNT, RH
49 86370220 1 BRKT, DECK MOUNT, LH
50 86274660 2 SCREW, 3/8-16 X 1.5 HHCS STL GR5 ZNPLT
51 86005770 2 NUT, 3/8-16 HEX NYLOCK STL GR2 ZNPLT
52 86005730 2 NUT, 3/8-16 HEX STL GRA ZNPLT
53 73110060 2 HEXAGON NUT M10 -8-A3E ISO 4032
54 73100410 2 KNURLED NUT M10- St-E2E DIN 467
55 64014750 2 EYE SCREW LB-5.6 M10x70 (3)*
56 44812950 2 TIE ROD (3)*
57 86370120 4 SPACER, .319DX.75DX.75L,AL
58 86394860 - ADD-ON KIT, TENSION ROD (3)*
- 27630040 - BRUSH HEAD R 65 CM W/SIDE DECK, COMPLETE
