8586367610 Chariot CS26
Scrub Deck Lift - Disk
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86365440 1 PIN, CLEVIS 5/16 X 2.25 PL
2 86008660 1 COTTER 5/16" RING
3 86005630 4 NUT 3/8-16 HEX NYLOCK THIN SS
4 86255450 2 SPRING .96D X 4.0L X.135W
5 86275510 2 SCREW 3/8-16 X 4.5" HHCS GR5
6 86010770 2 WASHER 7/16ID X1DX.08 FLT SS
7 86011950 1 ACTUATOR, 36VDC 3.5 STRK
8 86273850 2 SCREW 1/4-20 X 2 HHCS SS
9 86010780 2 WASHER 1/4 SPLIT LOCK PLTD
10 86005810 2 NUT 1/4-20 HEX NYLOCK SS
11 86361710 1 PLATE, ACT SPG, DECK, CS26
12 86274110 2 SCR, 1/4-20 X 1/2 SHCS
13 86361720 1 BRKT, ACT SPGS, DECK, CS26
14 86002830 1 CABLE TIE .375 X 24.7
