8786367610 Chariot CS26
Scrub Deck Lift - Cylindrical
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86370800 1 BRKT, SOLENOID CS26 SP
2 86370720 1 PLATE, CYL DECK ATTACHMENT
3 86370280 1 BRKT, LIFT MOUNT, RH
4 86370270 1 BRKT, LIFT MOUNT, LH
5 86370260 1 ASM, DECK LIFT
6 86270250 1 BRKT, ACTUATOR MOUNT
7 86370240 1 PIN, CLEVIS 1/4 X 2.75 STL ZNPLT
8 86368240 2 NUT, 5/16-18 FLGNLOCK, SS
9 86367250 2 WASHER, .344 X 1.13 X .09 SS
10 86320880 1 ACTUATOR, 36 VDC, 3.0” STK, 8.74 LNG
11 86276950 2 SCR, 1/4-20 X 3.4 CARRIAGE SS
12 86276490 2 SCR, 5/16-18 X 5.8 HHCS SS
13 86272620 1 PIN, CLEVIS 1/4 X 1.125 STL ZNPLT
14 86270990 1 NUT, 10-32 HEX NYLOCK SS
15 86228790 2 BEARING, FLG. .88 OD X .75 ID X .75
16 86010630 2 WASHER, 1/4 X 5/8 FLAT SS
17 86008650 2 COTTER, 1/4 RING
18 86360310 4 NUT,1/4-20 FLG SS NYL
19 86008660 1 COTTER, 5/16 RING
20 86006200 1 PIN, CLEVIS 5/16 X 1.5 STL ZNPLT
