8986367610 Chariot CS26
Scrub Deck Skirts
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86358580 1 SKIRT, SCRUB DECK, 26" IN
2 86361590 1 FLEX STRIP BRUSH, 26" SKIRT
3 86005810 6 NUT 1/4-20 HEX NYLOCK SS
4 86364880 7 SCREW, 10-32 X 5/8, PH, CSKH, SS
5 86006870 2 SCREW #10B X 1/2 PHSM BLK
6 86335450 2 WASHER, #10 X.75ODX.040, NYL, BLK
7 86358570 2 ACCESS COVER, DECK
8 86358560 1 DECK, SCRUB, 26" IN
9 86273810 10 SCREW, 1/4-20 X 1 HHCS SS
10 86358620 1 MOUNT, AQUAMIZER, DECK, LH
11 86242130 4 KNOB, HEX PRESS-LOC WING
12 86270990 7 NUT 10-32 HEX NYLOCK SS
13 86358630 1 MOUNT, AQUAMIZER, DECK, RH
14 86361670 1 BLADE, AQUAMIZER, RH
15 86361680 1 BLADE, AQUAMIZER, LH
To Next Page
