Windsor Chariot 3 User Manual
4
of 1
of 1 rating
153 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
93
8
6367
610
Cha
ri
ot C
S26
Scr
ub Deck Mounting - Cylindrical
RE
F
P
AR
T N
O.
Q
TY
DE
SCRI
PTI
ON
SERI
AL
NO
.
FRO
M
NO
TE
S
1
86
37
0830
4
SC
RE
W
, 5/16
-18
X 2
.0,
PNH
,
MS,
SS
2
86
37
0120
4
SP
ACE
R, .3
2 I
D X
.7
5D X
.75
L, A
L
3
86
27
6890
2
SC
RE
W
, 5/16
-18
X .
75
PH
TRHM
S
SS
4
86
36
8240
6
N
UT
,
5/16
-1
8, FL
GNYLO
CK
,S
S
5
73
03
1070
3
SC
RE
W
, 5x16
-1
0.9
-P2
R
(K-
In6
Rd)
92
94
Table of Contents
Machine Data Label / Overview
2
Table of Contents
3
Safety
5
Important Safety Instructions
5
Hazard Intensity Level
7
Safety Label Locations
9
Operations
10
Technical Specifications
10
How this Machine Works
12
Components
13
Drive Controls
15
Scrub Controls
18
Pre-Run Machine Inspection
20
Starting Machine
20
Emergency Stop Procedures
20
Filling Solution Tank
20
Normal Scrubbing
21
To Begin Scrubbing
22
To Stop Scrubbing
22
Double Scrub
22
Emptying and Cleaning Tanks
23
Solution Tank
23
Optional Chemical Metering System
23
Squeegee Disk
24
Squeegee - Cylindrical
25
Maintenance
27
Service Schedule
27
Batteries
28
Changing Batteries
32
Battery Charger Programming
33
Squeegee - Disk
34
Squeegee - Cylindrical
34
Squeegee Blades
35
Scrub Deck - Disk
36
Scrub Brushes
37
Finished Floors
37
Replacing or Installing Scrub Brushes - Disk
38
To Replace Scrub Brush Motors
39
Brush Motor Carbon Brush Replacement
39
Scrub Deck - Cylindrical
40
Replacing or Installing Scrub Brushes - Cylindrical
41
Actuator Scrub Deck Removal / Replacement
42
Scrub Deck Actuator Adjustment
42
Circuit Protection
43
Solution
44
Solution Strainer
45
Solenoid Valve
45
Chemical Bottle (Optional)
45
Flow Meter (Optional)
45
Vacuum
46
Recovery Tank Float Shut-Off
47
To Repair or Replace Vacuum Motor
47
Drive Motor
48
Electric Parking Brake Engagement
49
Drive Motor Carbon Brush Replacement
49
Transporting
50
Troubleshooting
51
Controller Fault Codes
53
Parts
55
Bumper
56
Console
58
Console Mounting
60
Control Panel - Upper
62
Control Panel-Lower
64
Control Panel Mounting
66
Decals
68
Drive Mounting
70
Frame
72
Platform
74
Platform Footbox & Rear Wheels
76
Rear Cover
78
Scrub Deck - Disk
80
Scrub Deck - Cylindrical
82
Scrub Deck Lift - Disk
84
Scrub Deck Lift - Cylindrical
86
Scrub Deck Skirts
88
Scrub Deck Mounting - Disk
90
Scrub Deck Mounting - Cylindrical
92
Scrub Brush/Pads Driver - Disk
94
Scrub Brush/Pads Driver - Cylindrical
96
Solution System - Disk
98
Solution System - Cylindrical
100
Squeegee - Disk
102
Squeegee - Cylindrical
104
Squeegee Lift
106
Squeegee Swing - Disk
108
Squeegee Swing - Cylindrical
110
Steering
112
Tank
114
Vacuum
116
Wiring-Batteries
118
Wiring-Components
120
Wiring 1
122
Options
137
Chemical Metering Solution System - Disk
138
Chemical Metering Solution System - Cylindrical
140
Control Panel - Chemical Solution Metering
142
Onboard Charger
144
Battery Exchange - 1
146
Battery Exchange - 2
148
Battery Exchange - 3
150
Suggested Spare Parts
152
Serial Numbers
153
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Windsor Chariot 3 and is the answer not in the manual?
