1186408800 Spare Parts List - Clipper Duo
Control Panel
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86002010 2 BOOT, 3/8 CIRCUIT BREAKER
2 86001980 1 BREAKER, 15A 250VAC 50VDC
3 86215670 1 BREAKER, 8A VDE CIRCUIT
4 86308020 1 GASKET, HANDLE CTRL PNL
5 86173030 4 SCR, M4 X 6, PHMS, ISO7045, PL
6 86173300 1 WASHER, M8, FLAT ISO7089, SST
7 86005640 3 NUT, 10-32 HEX NYLOCK
8 86172640 1 NUT, M8, NYLOCK, ISO7040, SST
9 86223010 1 PLATE, CONTROL PANEL
10 86301820 1 TRANSFORMER, 24V, 115V
11 86224730 1 SPRING, COMP, 12MM OD X 12.7MM
12 86224930 1 STRAIN RELIEF, 14/3 STRAIGHT
13 86007130 1 SWITCH DPDT 2-POSITION ROCKER
14 86007200 1 SWITCH, DPDT3-POSITION ROCKER
15 86007140 1 SWITCH, SPST 2- POSITION ROCKER
16 86010640 6 WASHER, #10 LOCK EXT STAR SS
17 86295700 1 BRKT, ELECTICAL SEPARATOR
18 86391130 1 BRKT, HANDLE TRANSFORMER
19 86276820 5 SCR, 10-32 X 1/2 PTHMS BLK NP
20 86298690 1 RELAY, 24VAC
21 86297750 1 CORD ASM, 14/3 X 22 PGTL
22 86233170 1 CLAMP, 3/8 NYLON UL/CSA
23 86234110 1 CORD SET, 14/3 SJTW-A X 50' YLW
24 86391120 1 BRKT, HANDLE RELAY
25 86006620 4 SCR, 6-32 X 1/4 PPHMS SS
26 86005700 1 NUT 10-32 W/STAR WASHER PLTD
