2386408800 Spare Parts List - Clipper Duo
Handle Release Lever
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86215240 2 BEARING, FLANGE, 10M ID
2 86215630 1 BRACKET, LEVER, CONSOLE
3 86300570 1 CONSOLE, BRC 45/45 C, TRM, BLK
4 86008650 4 COTTER, 14" RING
5 86218190 2 GASKET, CONSOLE, TUBE
6 86218020 1 GASKET, LEVER, HANDLE
7 86335630 1 LEVER, PIVOT HANDLE YLW
8 86222280 4 NUT, 10-32 HEX NYLOCK SS
9 86295820 2 PIN, LEVER SHAFT
10 86221840 1 PIN, LINKAGE
11 86222550 1 PIN, PIVOT, LEVER
12 86222990 1 PLATE, PIVOT, LEVER
13 86173030 4 SCR, M4 X 6, PHMS, ISO7045, PL
14 86293370 4 SCR, M8X70, HHCS, GR 10.9 PLT
15 86224540 4 SPACER, 8.5 ID X 45L
16 86254970 1 SPRING, COMP 18MM OD X 83 X 2
17 86259400 1 WASHER, THRUST .51 ID X 1 ODBRO
18 86225950 1 WELDMENT, PIVOT SHAFT, LEVER
To Next Page
