Winegard sensar series - Page 2

2
➧
TOWARD FRONT
OF VEHICLE
1/8" DRILL BIT
10 HOLES. DO NOT
DRILL THROUGH CEILING.
1-3/4" DIA.
DRILL COMPLETELY
THROUGH CEILING
(Template)
1/2" DIA.
NOTE: DO NOT DRILL
THOUGH CEILING IN
EXPOSED AREA.
Rev. 1-98
➧
MINIMUM OF 5 FT.
CLEAR SPACE
RV-3090/4090/5090 TEMPLATE
