Wingsland S6 - Aircraft Diagram

10
11
12
13
14
15
16
169 mm
79 mm
138 mm
32.6 mm
3
Aircraf t Dia gr am
1
2
3
4
5
6
7
9
8
11
12
13
14
15
16
10
① Propeller Lock Screw
② Motors
③ Arm
④ Extended port
⑤ Built-in Camera
⑥ Flashlight
⑦ Front LEDs indicator(Green)
⑧ Ventilation Slot
⑨ Propellers
Footpads
Optical flow sensor
Ultrasonic module
Rear LEDs(orange)
Battery
Battery lock catch
Power button
Camera micro SD card slot
Micro usb port
S6 User Manual
