5 Version 1.0
How the 4P GDR works
Do not open the door while the program is running. There is a risk of
hot water spraying out of the machine. Opening the door while the
program is running will abort the program.
Do not sit or stand on the open door.
After you start the 4P GDR, it will cycle through 6 washing steps. In each of these 6
steps you can program the whether the step is active, the water temperature, the length
of the wash cycle and the kind and amount of chemicals that you want to use. After
each of these wash cycles, the machine is completely drained to prevent chemical
interference between each step.
After 6 cycles a dry cycle is activated. The length of the dry cycle is programmable as
well.
Start wash cycle
Read wash
parameters
Is step active?
Fill tank with
heated water
Dispense selected
chemicals
Run wash
cycle
Increase step
counter
6 steps done?
No
No
Run dry cycle
Done
