9 Version 1.0
Parameter Menu
Param. Possible
Values
Default
value
Description
Washing step 1: Nickel removing with Nitric acid
P11 On/Off On Wash step active.
P12 15…20 15 Water level in liters
P13 20…60 35 Water temperature while washing in Celsius.
P14 0,1,2,3 1 Dosing pump. 0 indicates no dosing (rinse step)
P15 0…50 20 Dosing level in ml/Liter
P16 1...99 40 Circulation time in minutes
Washing step 2: Resist stripping with Alka 220
P21 On/Off On Wash step active.
P22 15…20 15 Water level in liters
P23 20…60 35 Water temperature while washing in Celsius.
P24 0,1,2,3 2 Dosing pump. 0 indicates no dosing (rinse step)
P25 0…50 6 Dosing level in ml/Liter
P26 1...99 40 Circulation time in minutes
Washing step 3: Rinsing at 50 degrees
P31 On/Off On Wash step active.
P32 15…20 15 Water level in liters
P33 20…60 50 Water temperature while washing in Celsius.
P34 0,1,2,3 0 Dosing pump. 0 indicates no dosing (rinse step)
P35 0…50 3 Dosing level in ml/Liter
P36 1...99 5 Circulation time in minutes
Washing step 4: Rinsing at 60 degrees
P41 On/Off On Wash step active.
P42 15…20 15 Water level in liters
P43 20…60 60 Water temperature while washing in Celsius.
P44 0,1,2,3 0 Dosing pump. 0 indicates no dosing (rinse step)
P45 0…50 3 Dosing level in ml/Liter
P46 1...99 5 Circulation time in minutes
Washing step 5: spare
P51 On/Off Off Wash step active.
P52 15…20 15 Water level in liters
P53 20…60 35 Water temperature while washing in Celsius.
P54 0,1,2,3 1 Dosing pump. 0 indicates no dosing (rinse step)
P55 0…50 3 Dosing level in ml/Liter
P56 1...99 15 Circulation time in minutes
Washing step 6: spare
P61 On/Off Off Wash step active.
P62 15…20 15 Water level in liters
P63 20…60 35 Water temperature while washing in Celsius.
P64 0,1,2,3 1 Dosing pump. 0 indicates no dosing (rinse step)
P65 0…50 3 Dosing level in ml/Liter
P66 1...99 15 Circulation time in minutes
Washing step 7: Drying
P71 On/Off On Dry step active.
P76 1...99 30 Dry time in minutes
