Software | 4 | English
Operating instructions CTR Series | 89014478; 2020-06 | 19
Set the rinse aid dosing amount
1 2
Item Name
1 Transport speed
2 Reset to default setting
Configure an external detergent dosing device connection
The service technician requires this menu when he connects an external detergent dosing device to the ware-
washer. }30
21
Item Name
1 Reset to default setting
2 Voltage at the “Detergent” terminal
– while the warewasher is filling up
– parallel to the solenoid valve
Configure an external rinse aid dosing device connection
The service technician requires this menu when he connects an external rinse aid dosing device to the ware-
washer. }30
21
Item Name
1 Reset to default setting
2 Voltage at the “Rinse” terminal
– parallel to the rinse pump
– parallel to the solenoid valve
See also
2 Connecting external dosing devices [}29]
