12 Exploded views and spare parts
12.1 Spare parts
No.
Description
TR10
TR15
TR20
TR24
TR28
TR40
TR
5
0
1 Burner IB3200 IB3200 IB3200 IB3200 IB3200 IB3200 IB3200
2 Ignition electrode GA3400 GA3400 GA3400 GA3400 GA3400 GA3400 GA3400
3
Ignitioncable
IY3949
IY3949 IY3949 IY3949 IY3949 IY3949 IY3949
4 Ionisation electrode GA3402 GA3402 GA3402 GA3402 GA3402 GA3402 GA3402
5 Flue fan GA4500 GA4500 GA4500 GA4500 GA4500 GA4514 GA4514
6 Gas controle valve GA3394 GA3394 GA3394 GA3394 GA3394 GA3394 GA3394
7 System Fan IB4816 IB4816 IB4816 IX4201 IX4201 IX4203 IH4206
8
Main board, EBM966 GY5901
GY5901 GY5901 GY5901 GY5901 GY5901 GY5901
9 pressureswitch IB3901 IB3900 IB3911 IB3900 IB3901 IB3902 IB3902
10 NTC cable set GY3934 GY3934 GY3934 GY3934 GY3934 GY3934 GY3934
11 Gasket set TR GA6712 GA6712 GA6712 GA.6712 GA.6712 GA6714 GA6714
15 Display pcb GY5902 GY5902 GY5902 GY5902 GY5902 GY5902 GY5902
24 External temp.sensor IY3931 IY3931 IY3931 IY3931 IY3931 IY3931 IY3931
25 Rectifier block IY3921
IY3921 IY3921 IY3921 IY3921 IY3921 IY3921
No.
Description
TR60
TR80
TR100
TR125
TR150
1 Burner IB3204 IB3204 IB3204 IB3204 IB3204
2 Ignition electrode GA3400 GA3400 GA3400 GA3400 GA3400
3 Ignitioncable
IY3949 IY3949 IY3949 IY3949 IY3949
4 Ionisation electrode GA3402 GA3402 GA3402 GA3402 GA3402
5 Flue fan GA4516 GA4516 GA4517 GA4517 GA4517
6 Gas controle valve GA3314 GA3314 GA3314 GA3314 GA3319
7 System Fan IX4201 IX4203 IH4206 IX4207 IX4207
8 Main board EBM966 GY5901 GY5901 GY5901 GY5901 GY5901
9 pressureswitch IB3904 IB3904 GA3968 GA3966 GA3964
10 NTC cable set GY3934 GY3934 GY3934 GY3934 GY3934
11 Gasket set TR GA6716 GA6716 GA6716 GA6716 GA6716
15 Display pcb GY5902 GY5902 GY5902 GY5902 GY5902
24 External temp. sensor
IY3921 IY3921 IY3921 IY3921
IY3931
25 Rectifier block IY3921
IY3921 IY3921 IY3921
26 Fan relay
IK5200 IK5200 IK5200
