TORCH WIZARD INSTALLATION & OPERATION MANUAL
6.4 PARTS LIST
Please reference model and serial number when ordering replacement parts.
1 5193A2 PLASTIC HANDLE 1
2 5448T21 16MM ID ALLOY 932 FLANGE BUSHING 1
3 1734A12 Front Door Latch 1
4 10335A75 Lock 2
5 41451 3/8 ALUMINUM BACK UP WASHER 2
6 41406 M8-1.25 X 25 FHCS ZINC 2
7 41317 M6-1.0 X 10MM BHCS ZINC 9
8 41301 M4-.7 X 10 BHCS ZINC 13
9 40147 M4-07 NYLOC NUT ZINC 7
10 90597 M8-1.25 X 12 LSHCS BLACK OXIDE 2
11 41299 M4-.7 X 6MM BHCS ZINC 2
12 41307 M6-1.0 X 14MM SHCS ZINC 3
13 39856 M8-1.25 X 16 FPSS BLACK OXIDE 1
14 35879 M4-0.7 X 10 ZINC SHCS 2
15 41363 M4-.7 X 10MM FHCS ZINC 2
16 35915 M6-1.0 X 14MM SHCS ZINC 2
17 35891 M4-0.7 X 60 ZINC SHCS 4
18 41389 M6-1.0 X 14 FHCS ZINC 14
19 41391 M6-1.0 X 18 FHCS ZINC 4
20 35918 M6-1.0 X 20 SHCS ZINC 6
21 35921 M5-.8 X 14 SHCS ZINC 4
22 40059 M6 X 20MM DOWEL 12
23 35934 M8-1.25 X 20 SHCS ZINC 2
24 41705 M5-.8 X 90 SHCS ZINC 4
25 24766 M5 HIGH COLLAR LOCK WASHER 8
26 40353 M4 ZINC FLAT WASHER 7
27 41293 M3-.5 X 6 BHCS ZINC 2
28 H5161-L27WHP MOVING PARTS WARNING TAG 1
29 NCS-TAG-3 TAG 1
30 USA STICKER TAG 1
31 EL-NCS-A-20-SERIAL TAG MODEL/SERIAL TAG 1
32 NCS-NOZZLE-DEPTH-WARN NOZZLE DEPTH WARNING LABEL 1
33 NCS-TAG-8 TAG 1
34 NCS-TORCH WIZARD-LABEL TORCH WIZARD EMBOSSED LABEL 1
35 NCS-24 V-BLOCK 2
36 NCS-25 BASE PLATE 1
37 NCS-29 TOP PLATE 1
38 NCS-31 ADAPTER PLATE 1
39 NCS-32 SUPPORT NEST 1
40 NCS-34 SADDLE PLATE 1
41 NCS-86 STAINLESS FRONT COVER 1
42 NCS-36 STAINLESS REAR COVER 1
43 NCS-37 CATCH PAN 1
44 NCS-38 RISER BLOCK 2
45 NCS-39 THREADED ROD 1
46 NCS-40 EXTENSION FITTING 1
47 NCS-41 COVER 1
48 NCS-42 COVER 1
49 NCS-83-AVBC-18B FACE PLATE 1
50 NCS-27 SIDE PLATE (LH) 1
51 NCS-28 SIDE PLATE (RH) 1
52 NCS-46 REAR COVER HINGE 1
53 NCS-47 FRONT COVER HINGE 1
54 NCS-45 CLAMP CYLINDER SPACER 1
55 NCS-81 CATCH TRAY LOCATOR 2
56 NCS-98 MOTOR MOUNT 1
57 NCS-97 MOTOR MOUNT 1
58 NCS-102 SIDE COVER 1
59 NCS-87 ANTI-SPATTER SHIELD 1
60 NCS-115 EXTENSION FITTING 2
61 NCS-118 COVER 1
62 9688K124 PLASTIC PLUG 5
63 EC-18 CAPLUG 1
64 CPT-6 AIR INLET PLUG 1
65 9688K127 ROUND PLUG 1
66 9688K221 PLASTIC PLUG 2
67 W0970530053U 1-4 NPT SFE MUFFLER 2
68 109AL-04 1/4 NPT BRASS PLUG 2
69 MGQM25-50 GUIDED AIR ACTUATOR SLIDE 1
70 HHB-107459 MANIFOLD & VALVES SUB ASSY 1
71 NCS-16-MOTOR AIR MOTOR 1
72 KQB2L06-01S 1/4 NPT MALE ELBOW 1
73 74965K65 2.00" PIECE OF SHRINK TUBE 2
74 TRB0604B-100 6MM FLAME RESISTANT BLACK TUBING 1
75 IN-289-2006 WELD SPATTER COVER 2
76 KQ2T08-00 8MM UNION TEE FITTING 1
77 CDQ2B40-40DZ SMC 40MM BORE X 40MM STROKE 1
78 KQ2E06-00A FITTING, BULKHEAD 1
79 AS2201F-01-08ST FLOW CONTROL 2
80 KQ2R06-08 6MM TUBE X 8MM REDUCER 1
81 KQ2L08-01S 90 DEGREE FITTING 2
82 11751 DIN RAIL 1
83 0382860000 TERMINAL END BRACKET 2
84 14RB10 WIRE END W/#10 HOLE-16 GA. WIRE 1
85 1753280000 TERMINAL BLOCK 12
86 1754190000 END PLATE 1
87 1754290000-2 JUMPER 2
88 1754290000 JUMPER 1
89 32191 INSULATED TERMINAL FEMALE 4
90 ULV4F2BSS335 PUSH BUTTON 1
91 ROCCA-09-B-16C 9-PIN RECEPTACLE 1
92 D-Z73 SWITCH 1
93 D-A93V SWITCH 1
94 PFA-27 SPACER 2
Cutting Blade NCS-WCS-19
Wire Back Plate NCS-WCS-16
Wire Cutter Replacement Parts
Clamping Block NCS-WCS-07
Replacement Spring C0240-045-1000-S
NOTE: Wire cutter not included on
EL-NCS-20 model
