MPR52-ENG User Manual
5
In compliance with
USA: , 47 CFR 15 Subpart B
CAN RSS-Gen/CNR-Gen
AUDIO OUTPUT
• Audio output : Electronically balanced on 5 pin mini-XLR Female
connector
analogue or digital (SW selectable)
• Digital line 1 & 2 : Electronically balanced on 5 pin mini-XLR Male
connector
• Digital line-output : AES3 @ 48 kHz
• Audio line impedance : ≤ 200 ohm
• Headphone-output : 3.5mm (TRS) stereo plug, locking (M6 x 0.5 thread)
with 50mW @ 32 Ohm
NOTE [1]: RMS value, 22 Hz / 22 kHz, unweighted.
The MPR52ENG receiver complies with ETSI specifications: ETS 300 422
VARIANTS: MPR52-ENG- <Freq Range>
▪ FREQUENCY RANGE
B1 470-800 MHz, 940-960 MHz (for USA), 960-1160 MHz (DME)
B2 470-800 MHz, 960-1160 MHz (DME), 1240-1260 MHz (for Japan)
B3 470-800 MHz, 960-1160 MHz (DME), 806-810 MHz (for Japan)
