TREE MENU
Infrared
•Active
•Load [Preset1,Preset2,Preset3, User1, User2, factory]
•Save [User1, User2]
Preset
•Headphones
•Volume [Min, -56,...,-5, Max]
•Rx [Rx1(L); Rx2[r]...
•Signal [LINE, TSQ>LINE]
•Output type [Analog, AES3]
•OUT RX1 [-35, ...., 18dBu]
•OUT RX2 [-35, ..,18dBu]
•Sig.ph.RX1 [0,180]
•Sig. ph. RX2 [0,180]
•Cal.Tone [OFF; 0dB, -18dB]
Audio Settings
•Power on [Rx1+RX2, RX1, RX2]
•Edit RX1/2
•Name
•Frequency
•Squelch [OFF, from 0 to +46 dBμV @3dBstep]
•Expander [ENR Wis, ENC WIs, ENS, ENR-1.2, ENC-1.2, JNR Wis, JNC Wis, SEN, SR, AL,
EVO, OVL, DSP_Q5X]
•Tone sq. [OFF, ON]
•Sync
•Settings
•Display
•Contrast [1÷5]
•Low Timeout
•Off Timeout
•Direction [Up/down]
•Led
•Mode [Full, Alarms, OFF]
•Brightness [0÷5]
•RX IF BW [NB, WB]
•Op. mode [Ant. div, Freq. div. True div.]
•Scan
•Act. Code
Advanced
•Supply
•Model
•Serial
•FW
•HW
•Errors
Info
