WisyCom MTP41 - Device Menu System; Menu Navigation Overview

MTP41 User Manual
6
DISPLAY MENU
MENU
STATUS
PRESET
Current / Load
FACTORY/USER/PRESET1/2/3/4/5/6/7/8
Save
USER
TUNING
CH 00-59
GR 00-39
Freq
1: 470.000÷640.000
2: 566.000÷798.000
3: 510.000÷698.000
AUDIO
AF In Gain
AF Level
-60 ÷ +40 dB (1dB step)
-54 ÷ +46 dBu (1dBu step)
Phase 0/180
HP Filt
Flat/60/80/120/170/250/400Hz
Noise R.
ENR-Wisy/ENC-Wisy
MIC
Mode
2 wires/2wires+bias/3 wires
PTT
Disable/Normal/Muting/No Data
RF/Battery
RF Power
10/50mW *
Battery Alkaline/NiMH/Lithium
LED
Led Light 0÷16
Led Mode
None/ModPeak/PTT
INFO
IRDA
Name
Lock
Preset parameters
* Depending on the Power Profile
