WiXHC MACH3 MK3-V User Manual

Sin gal Instruction
Offer 16pcs Input IO, All IO active low, input current 5mA, support
6-24V signal input.
Signal explanation as follow:
X-HOME：X Axis home signal input, corresponding MACH3 input IO is：P1.0
Y-HOME：Y axis home signal input, corresponding MACH3 input IO is：P1.1
Z-HOME：Z Axis home signal input, corresponding MACH3 input IO is：P1.2
A-HOME：AAxis home signal input, corresponding MACH3 input IO is：P1.3
PROBE: Tool setting signal input, corresponding MACH3 input IO is：P1.4
IN5-IN15：Input IO，MACH3 Input IO are：P1.5-P1.15
Input signal
MKX support spindle speed adjustment, support inverter port or PWM port.
MKX spindle port speed adjustment output, support 2 types：0-10V analog
voltage output or 0-5V analog voltage output or 5V PWM signal output
When you are using analog voltage output for speed adjustment, you need to
offer DC voltage to our breakout board, DC voltage value related to max analog
voltage output value. For example, DC voltage output:10V, and analog voltage
output will be between 0-10V.
Hardware Instruction
www.cdxhctech.com
ChengDu XinHeCheng Technology Co.,Ltd
Inverter
<4>

WiXHC MACH3 MK3-V Specifications

General

Brand	WiXHC
Model	MACH3 MK3-V
Category	Controller
Language	English
