WLINK WL-R320 Series User Manual

WL-R320 Series Router User Manual
27
Parameter
Instruction
Default
Mode
Forward/DNAT Options
Forward
DMZ Host Address
The destination IP address inside the LAN. The DMZ will be
available after configured host IP address.
Null
Name(unique)
Indicate the ordinal of the list.
Null
Port
Configure external port of router which can be accessed by
other hosts from internet.
Null
Protocol
UDP,TCP, Both UDP/TCP Options
UDP+TCP
Intranet Address
The destination address inside the LAN.
Null
Intranet Port
The internal port of router’s LAN
Null
Step 2 Please Click “Apply“ to finish.
----End
2.5.9
Port Proxy
Step 1 Network->Port Proxy to enter the setting page.
