WL-R320 Series Router User Manual
49
2.9.5 Remote IO
Step 1 Application > Remote IO to check or modify the relevant parameter.
GPIO Value Format
Item
Value
Indication
GPIO number
g1
g1 for GPIO1(G1) port
g2 for GPIO2(G2) port
g3 for G3 port(Reserved)
First Digit
1
Output(DO)
0
Input(DI)
Second Digit
1
High Level(3.3v)
1
Low Level(0v)
Separator sign
;
Step 2 Please click ”Apply” to finish.
The remote IO feature support to remotely control IO by SMS and TCP protocol, and support IO status
to report server by SMS and TCP protocol.
