8.2 Setting pressure reducer
Setting pressure reducer without laptop
Start service program
service routine setting
pressure reducer start.
Remove screw-cap on descaling nozzle.
Screw auxiliary nipple to accept plug-in connector into
the descaling nozzle.
Mount auxiliary tool on descaling nozzle.
Press field
Start
Supply valve opens
Read pressure on pressure gauge.
Set pressure to 1.8 bar at pressure reducer.
Finish test.
Dismantle setting equipment and remove auxiliary
nipple.
Replace filler cap.
Setting pressure reducer with KonfigTool
Adjust test environment
set pressure reducer start
Remove screw-cap on descaling nozzle.
Screw auxiliary nipple to accept plug-in connector into
the descaling nozzle.
Mount auxiliary tool on descaling nozzle.
Start test on laptop
Supply valve opens
Read pressure on pressure gauge.
Set pressure to 1.8 bar at pressure reducer.
Finish test
Dismantle setting equipment and remove auxiliary
nipple.
Replace filler cap.
