CNC210 Operating Manual
1
Three jaw chuck Φ100
1
2
CNC210-02B-001
Spindle
1
3
GB897-88
Double end studs M8╳30
4
4
GB41-2000
Nut M8
4
5
GB1096-79
Key 6╳40
1
6
GB70-85
Screw M6╳14
6
7
CNC210-02B-002
The spindle end cover
1
8
CNC210-02B-003
Shield ring
1
9
GB/T292-94
Duplex angular contact bearings in pairs 7008C-DB P4
1set
10
CNC210-02B-018
Spacer
1
11
CNC210-02B-019
Spacer
1
12
CNC210-02B-005
Clamping ring
1
13
Dental cover nut YSF M40╳1.5
1set
14
Dental cover nut YSF M35╳1.5
1set
15
Wedge belt 7-PJ594
1
16
CNC210-02B-011
Spacer
1
17
CNC210-02B-010
Spindle pulley
1
18
CNC210-02B-009
synchronous pulley A
1
19
GB70-85
Screw M5╳14
6
20
Synchronous belt 130XL037
1
21
CNC210-02B-008
End cover
1
22
CNC210-02B-007
Bearing gland
1
23
GB/T276-94
Bearing 6007-Z P5
2
24
CNC210-02B-006
Bearing retainer
1
25
GB95-85
Flat washer Φ8
4
26
GB97-86
Spring washer Φ8
4
27
GB70-85
Screw M8╳30
4
28
CNC210-02B-004
Spindle box
1
29
CNC210-02B-017
Cover
1
30
GB70-85
Screw M5╳8
2
31
CNC210-02B-015
Adjust seat
1
32
GB70-85
Screw M6╳16
4
33
GB41-2000
Nut M6
2
34
GB70-85
Screw M6╳30
2
35
Main motor 1.1KW
1
36
GB70-85
Screw M5╳20
4
37
GB1096-79
Key 4╳20
1
38
CNC210-02A-006
Motor seat
1
39
CNC210-02B-012
Motor pulley
1
40
GB/T78-2000
Six pyramid end screw M5╳8
1
41
GB70-85
Screw M8╳25
2
42
GB96-85
Flat washer 8
2
43
GB894.1-86
Shaft with elastic ring 15
1
