WMT CNC210 - Page 25

CNC210 Operating Manual
1
CNC210-03A-007
The adjusting screw
6
2
CNC210-03A-005
Briquetting
2
3
GB97-2000
Six pyramid end screw M4╳8
4
4
GB/T77-2000
Allen flat end set screws M4╳6
4
5
CNC210-03A-006
Carriage gib
2
6
WM180V-02-031
Scraping the crumbs board A
2
7
CNC210-03A-001
Carriage
1
8
GB/T276-94
Bearing 619/8-2Z
1
9
CNC210-03A-003
X axis ball screw seat
1
10
GB70-85
Screw M6╳25
2
11
GB/T818-2000
Screw M3╳8
8
12
GB118-2000
Taper pin 6╳40
2
13
GB70-85
Screw M8╳35
2
14
WM180V-02-032
Scraping the crumbs board B
2
15
CNC210-03A-008
Gib
1
16
CNC210-03A-016
Stand
1
17
GB/T68-2000
Screw M5╳10
2
18
CNC210-03A-017
Induction block A
2
19
GB41-2000
Screw M6
4
20
CNC210-03A-015
Rest adjust pad
1
21
Electric tool post LD4-CK0610
1
22
GB70-85
Screw M6╳30
4
23
GB/T818-2000
Screw M5╳10
4
24
GB95-85
Flat washer 5
4
25
CNC210-03A-014A
Apron cover
1
26
CNC210-03A-002
apron
1
27
CNC210-03A-012
X axis ball screw
1
28
CNC210-03-013
Bushing
1
29
GB/T292-94
Duplex angular contact bearings in pairs 71900C/DB
1set
30
CNC210-03A-011
Bearing spacer
1
31
CNC210-03A-013
Bearing spacer
1
32
CNC210-03-011
Bearing gland
1
33
GB70-85
Screw M4╳16
4
34
CNC210-03-014
Spacer
1
35
CNC210-03-005
Scraping the crumbs board B
1
36
GB810-88
Dental cover nut M10╳1
2
37
CNC210-03A-009
Junction box
1
38
CNC210-07-020
Drag chain bracket
2
39
GB70-85
Screw M5╳10
2
40
CNC210-07-019
Drag chain slot
1
41
GB/T818-2000
Screw M5╳8
2
42
Drag chain
1
43
GB70-85
Screw M5╳10
2
