CNC210 Operating Manual
11
WM180V-05A-005
Tailstock end cover
1
12
WM180V-05A-009
Calibration loop
1
13
WM180V-05A-004
Hand wheel
1
14
WM180V-05A-019
Nut
1
15
JB/T7270.1-94
Handle B-M5╳40
1
16
WM180V-05A-010
Leaf spring
1
17
GB1096-79
Key 4╳12
1
18
GB1155-79
Oil cup 6
1
19
GB/T79-2000
Screw M5╳6
1
20
WM180V-05A-006
Lock pressing sleeve
1
21
WM180V-05A-015
Lock screw
1
22
JB/T7270.1-94
Handle HY8310.1 B-M6╳50
1
23
WM180V-05A-018
Limit screw
1
24
WM180V-05A-014
The eccentric lock shaft
1
25
WM180V-05A-013
The long handle bar
1
26
JB/T7271.3-1994
The handle set
1
27
WM180V-05A-007
Sleeve
1
28
GB.T70.1-2000
Hexagonal cylindrical side screw set M4╳12
4
29
GB/T79-2000
Hexagonal cylindrical side screw set M5╳6
1
30
GB/T77-2000
Hexagonal cylindrical side screw set M6╳6
1
