Parts List & Exploded Views
EElleeccttrriicc CCooookkttooppss
CT15E PARTS LIST
Ref # Part # Description
1 801135 Glass Ceran Assy W/Keypad 15”, Sst
2 801351 Screw, 6x3/8”
3 807075 Board, Control, 15”
4 803143 Cable, Ribbon, 15” & 30”
5 802613 Light, Indicator
6 803267 Element Assy., Double, 2200 Watt, 15”
7 803266 Element Assy., Single, 1200 Watt, 15”
8 800511 Spring, Leeco
9 803261 Box, Burner, Inner, Insulation, 15”
10 806731 Box, Burner, Inner Assy., 15”
11 807074 Board, Relay, 15”
12 800414 Blower, Transverse
13 806729 Box, Burner, Outer Assy., 15”
14 802669 Retainer, Fan, Rivet
15 802668 Guard, Fan
16 805644 Moisture Barrier, CT15E
Not Shown
Part #
Description
809232 Power Conduit w/Terminal Block
800419 Terminal Block
801046 Scraper, Cooktop
801048 Gasket, Rubber, Cooktop Surround
801101 Cleaning Cream
803263 Harness, Power Inlet, 15”
802709 Hold Down Clamp Kit
802733 Harness, Fan, 15”, 30”, 36”
802772 Grommet, Edge
To Next Page
