8-4
Parts List & Exploded Views
EElleeccttrriicc CCooookkttooppss
Ref # Part # Description
1 803795 Glass Ceran Assy W/Keypad Stainless, 30", Sst
803796 Glass Ceran Assy W/Keypad, Black, 30", Blk
803797 Glass Ceran Assy W/Keypad, Platinum, 30", Plt
2 801351 Screw, 6x3/8”
3 807070 Board, Control, 30”
4 803143 Cable, Ribbon, 15” & 30”
5 802613 Light, Indicator
6 801863 Element Assy., Double, 2200 Watt, 30”, 36”
7 801865 Element Assy., Double, 1900 Watt, 30”
9 801860 Element Assy., Single, 1200 Watt, 30”, 36”
10 801861 Element Assy., Single, 1500 Watt, 30”, 36”
11 801866 Box, Burner, Inner, Insulation, 30”
12 806702 Box, Burner, Inner Assy., 30” (See S/N Breaks)
13 800414 Blower, Transverse
14 807071 Board, Relay, 30”
15 806700 Outer Burner Box Assy., 30” (See S/N Breaks)
16 802668 Guard, Fan
17 802669 Retainer, Fan, Rivet
18 800511 Spring, Leeco
19 806654 Moisture Barrier, CT30E
20 806035 Power Board Mtg Bracket 30
22 806023 Cooktop Fan Mounting Bracket
22 809232 Power Conduit w/Terminal Block
Not Shown
Part # Description
800419 Terminal Block
801046 Scraper, Cooktop
801048 Gasket, Rubber, Cooktop Surround
801101 Cleaning Cream
802671 Harness, Element, 30”
802709 Hold Down Clamp Kit
802733 Harness, Fan, 15”, 30”, 36”
802772 Grommet, Edge
CT30E PARTS LIST
