8-6
Parts List & Exploded Views
EElleeccttrriicc CCooookkttooppss
Ref # Part # Description
1 804744 Glass Ceran Assy With Keypad Invensy, 36", Sst
(See S/N Breaks)
804745 Glass Ceran Assy With Keypad Invensys, 36", Blk
(See S/N Breaks)
804746 Glass Ceran Assy With Keypad Invensey, 36", Plt
2 801351 Screw, 6 x3/8”
3 807073 Board, Control, 36”
4 803143 Cable, Ribbon, 36”
5 802613 Light, Indicator
6 801864 Element Assy., Triple, 2700 Watt, 36”
7 801861 Element Assy., Single, 1500 Watt, 30”, 36”
8 801863 Element Assy., Double, 2200 Watt, 30”, 36”
9 801860 Element Assy., Single, 1200 Watt, 30”, 36”
10 801862 Element Assy., Single, 1800 Watt, 36”
11 800430 Box, Burner, Inner, Insulation, 36”
12 806717 Box, Burner, Inner Assy., 36” (See S/N Breaks)
13 807072 Board, Relay, 36”
14 800414 Blower, Transverse
15 806715 Box, Burner, Outer Assy, 36” (See S/N Breaks)
16 802668 Guard, Fan
17 802669 Retainer, Fan, Rivet
18 800511 Element, Spring
19 810951 Moisture Barrier, CT36E
20 806035 Power Board Mtg Bracket 30
21 806023 Cooktop Fan Mounting Bracket
22 809232 Power Conduit w/Terminal Block
Not Shown
Part # Description
800419 Terminal Block
801046 Scraper, Cooktop
801048 Gasket, Rubber, Cooktop Surround
801101 Cleaning Cream
809301 Harness, Element, 36”
802709 Hold Down Clamp Kit
802666 Harness, Fan, 36”
800910 Harness, Power, Inlet, 36”
802772 Grommet, Edge
CT36E PARTS LIST
